Integrity Series Upright Lifecycle® with X Console (INCSX)

Multiple upright bike combinations offer comfortable and inviting experiences for any exerciser. The Integrity Series benefits from a sleek and modern design, and is rooted in more than 20 years of reliability and innovation. Each bike offers wireless internet connection, which provides valuable asset management data and insights about your exercisers.

Share on facebook
Share on twitter
Share on linkedin
Life Fitness

INTEGRITY X CONSOLE

  • 1.7″ touchscreen interface
  • Easy access to 21+ workout options
  • Simple Console
  • Easily accessible workout options
  • Bluethooth & NFC Connection

Learn More

BASE FEATURES

The Integrity Series Lifecycle® Bike is sleek, bold and durable. Easy adjustments, ergonomic grips, pedals and handles all make it enjoyable to ride. Aesthetic touches enhance the visual appeal of these bikes in any facility.

  • A COMFORTABLE RIDE

    Easy adjustment for a fine-tuned and ergonomically sound seat position. Wide pedals with simple buckle straps allow exerciser to get on and go.

  • ERGONOMIC RACING HANDLEBARS

    Handlebars are designed to offer three different exerciser positions. Choose from cruising, hybrid and race positions..

  • GENERATOR DRIVE SYSTEM

    Drive system with 8-ribbed poly-V belt resistance provides a smooth, quiet operation and requires limited maintenance.

Product Specifications

Handlebars

Remote Buttons

No

Saddle

Improved Confort Curve™ Seat

Interchangable Seat

Yes

Pedal

Pedal size

6.56 x 5.5" (17 x 14 cm)

Pedal Straps

Yes

Interchangable Pedals

Yes

Accessories Holder

Integrated Accessory Tray

Seat Adjustment

42 Fine-Tuned Seat Adjutments w/easy to reach height adjustment lever; Lowest: 18.25" (46 cm) Highest: 31.5" (80 cm) Delta: 13.25" (34 cm) Adustment 14" (36 cm)

Step-over height

21.14" (54 cm)

User Height Range

4'9" (10 cm) – 6'5" (15 cm)

Max User Weight

Stretching Platform

No

Transport Wheels

Yes

Drive System

Generator Drive System with 8-Ribbed Poly-V Belt resistance system

Resistance Level

Resistance Type

Hybrid Eddy current brake with brushless internal generator for low drag and high power capability

Belt Drive

Single stage drive with self-tensioning idlers for minimal mechanical drag and low maintenance

Multi-Ribbed Belt Drive

Yes

Generator

Generator

Crank size

165mm (6.5")

Touch

Yes

Telemetry

Yes

Self-powered

All non Discover consoles

Power Requirements

North America: 120V, 20A outlet with dedicated line, neutral, ground wires and dedicated circuit breaker, Japan: 100V, 20A; International: 230V, 10A outlet with dedicated line, neutral, ground wires and dedicated circuit breaker, Japan: 200V, 10A

Minimum Watts

29 Watts

Maximum Watts

900+

Minimum RPM

30 rpm

Assembled dimensions

Length 41.5" (105 cm), Width 24.5" (62 cm), Height 54.5" (138 cm)

Unit Weight
